Operating system

Embedded Linux^®

System

Channel

16 Channel (DW-PVX16W multi-sensor IP camera uses 4 channels in the recorder, one per sensor).

No. of PoE

16 Ch

Max supported resolution

IP camera max. 4K (3840×2160)

Communication protocol

ONVIF^®

PoE type

1Gbps, 802.3af

Display

Speed

480fps

Screen mode

1, 4, 9 and 16

Video-out

Monitor

True HD and VGA

resolution

1024x768, 1280x720, 1280x1024, 1920x1080, 2560x1600, 3840×2160 (4K)

Recording speed

Up to 480fps up to 4K resolution

Max. throughput

160 Mbps

Max. HDD bay

4 x SATA HDD, up to 32TB

Recording resolution

Dual-stream

Recording modes

Continuous, C+M, C+S, scheduled, sensor and motion detection recording

Pre-alarm recording, emergency recording, quick backup

Playback and search

Speed

x1, x2, x4, x8, x16, x32, x64, x100

Function

Intelli-search by time bar, calendar (date and time) and event search

Audio output

1 Ch

Alarm input/relay output

16Ch inputs / 4Ch outputs

PTZ control

RS-485, ONVIF

Transaction verification

TCP and USB-serial interface

LAN

1x gigabit ethernet (RJ45) – fixed IP, DHCP and DDNS

Access

Web viewer: Live, playback and configuration up to 10 multiple connections

Client monitoring software: Mac® (Apple® S/W), C3™ (CMS S/W)

Compatible mobile apps:

DW Mobile Plus
DW Witness
DW Site Viewer

Backup device

Local backup by USB, network backup by CMS

System recovery after power failure

Auto-reboot and journaling file system

Other function

Firmware upgrade

FTP, USB

Back-up

Remote, USB

Special features

Local PoE switch
Quick Setup under 3 minutes
Snapshot Notify™: Programmable interval camera image verification sent to an email
Event notifications via email, text and C3™ CMS and push notifications to mobile devices
Real-time temp alert
Digital Zoom in live and playback

Health check

Real-time system, network and PoE status monitoring

System operation

IR remote controller (optional), USB mouse, PTZ control by keyboard (optional)

Power requirements

110~240V A/C

Total PoE Power Budget

150W

Max. Power per Port

30W

Power consumption

300 W total power budget, 5.5A, 9.37W per PoE channel (simultaneous)

Operating temperature and humidity

41~104 °F (5~40 °C) / 20~90% RH

Dimension (WxDxH)

17.32” x 15.66” x 2.79” (440 × 397.8 ×71 mm), 1.5U

Certification

CE, FCC, KCC, WEEE, RoHS

Warranty

5 year limited
