VIDEO

Operating system

Embedded Linux^®

System

Channel

16 Channel (DW-PVX16W multi-sensor IP camera uses 4 channels in the recorder, one per sensor).

No. of PoE

16 Ch

Max supported resolution

IP camera max. 4K (3840×2160)

Communication protocol

ONVIF^®

PoE type

1000Mbps, 802.3at

Display

Speed

480fps

Screen mode

1, 4, 9 and 16

Video-out

Monitor

True HD and VGA

resolution

3840×2160 (4K), 2560x1600, 1920x1080, 1280x1024, 1024x768

System operation

USB mouse, PTZ control by keyboard (optional)

PERFORMANCE

Recording speed

Up to 480fps up to 4K resolution

Max. throughput

160 Mbps

Recording resolution

Dual-stream

Recording modes

Continuous, scheduled, sensor and motion detection recording
Pre- and post-alarm recording, emergency recording, quick backup

Playback and search

Speed

x1, x2, x4, x8, x16, x32, x64, x99

Function

Timeline, calendar (date and time), event search, thumbnail search, smart motion search

Channel and resolution

1 and 4 main-stream, 9 and 16: sub-stream

Audio input/output

1Ch input/1Ch output

Alarm input/relay output

8Ch inputs / 4Ch outputs

PTZ control

RS-485, ONVIF

Storage

HDD interface

2 x SATA HDD

Maximum internal storage

Up to 32TB internal storage

HDD health check

Temperature, S.M.A.R.T. with email notifications
Real-time temp alert

Transaction verification

Text-in Based (USB to Serial support, TCP/IP Network), Display POS Data on Live and Playback

NETWORK

LAN

1x Gigabit Etherner (RJ45)

Protocols

IPv4, TCP/IP, DHCP, HTTP, RTSP, STMP, FTP, Zero Configuration, NTP, DDNS

Access

Web viewer

Live, playback and configuration, up to 10 connections

Video streaming functions

Dual recording for live and playback and dual-stream for local recording and network transmission
PathFinder™ P2P service

Client monitoring software

C3™ CMS, DW Mobile Plus™ and myDW™ web portal

Network functions

Live monitoring, remote playback and file backup

Remote system control

Remote system reboot, system management, notifications and remote PTZ control

Remote Time sync

Time synchronization to an NTP server (pool.ntp.org)

Remote system notifications

Notifications for system health, events and alarms

System recovery after power failure

Auto-reboot and journaling file system

Other function

Firmware upgrade

FTP, USB and CMS over Network

Back-up

Local backup by USB, network backup by CMS
Import and export settings, watermark and AVI file backup

Special features

Snapshot Notify™: Interval camera image verification
Event and push notifications via email, text and C3™
Digital Zoom in live and playback

Mobile client

DW Mobile Plus app for Apple® and Android® devices
DW Witness™ turns a smartphone or tablet into a surveillance camera

Health check

Real-time system, network and PoE status monitoring

GENERAL

Power requirements

48V DC, 2.5A

Total PoE Power Budget

TBD

Max. Power per Port

TBD

Power consumption

TBD

Operating temperature and humidity

32~113 °F (0~45 °C) / 10~90% RH

Dimension (WxDxH)

14.96" x 10.55" x 1.77" (380 x 268 x 45 mm)

Certification

CE , FCC, KC, NDAA, TAA

Warranty

5 year limited
