TEMPERATURE CAMERA

Image sensor

Micro-bolometer

Uncooled focal plane array

Resolution

384 x 288

Pixel pitch

17μ

Response wavelength

8μm to 14μm

Temperature sensitivity

50mK@f1.0, 30Hz, 300K

Lens

Lens type

Thermalized lens

Focal length

8.13mm, F1.16

HFoV / VFoV

47.4°/35.1°

Recommended distance range for best reliable measurement

6.5 to 16.4ft (2m to 5m) 10ft recommended

Minimum focus distance

1.64ft (0.5m)

Data output

Interface

Gigabit Ethernet (10/100)

Data

Temperature raw data of each pixel of the temperature sensor

Framerate

30Hz

VISIBLE CAMERA

Sensor

Image sensor

1/3" progressive CMOS sensor (Approximately 2.1MP/1080p)

Scanning sytem

16:9 progressive

Effective pixels

1920 (H) x 1080 (V)

Minimum scene illumination

0.2 lux (color), 0.1 lux (B/W)

Horizontal resolution

1000 TVL

Lens

Optic

4.0mm 70° HFOV

Video output

Interface

USB3.0 super-speed

Format

USB3.0 UVC compliant YUV 422 16bits, uncompressed video

Resolution and framerate

1920x1080p @ 30fps

GENERAL - CAMERA

Operation

Weight

2.2 lbs (1000gr) including a USB cable from the visible camera.

Dimensions (H x W x D)

3.18" x 5.31" x 5.92" (81 x 135 x 150.5mm)

Power Supply

12V DC

Operating Temperature

14°F ~ 104°F (-10°C ~ 40°C)

GENERAL - BLACKBODY

Operation

Fixed temperature set at the factory

104°F (40°C)

Effective radiant surface

Φ55

Temperature resolution

0.01

Temperature stability

±0.18°F (±0.1°C)

Temperature accuracy

±0.36°F (±0.2°C)

Emissivity

0.95

Temperature sensor

NTC 0.1%

Weight

0.72 lbs (330gr)

Dimensions (H x W x D)

2.83" x 2.83" x 1.92" (72 x 72 x 49mm)

Power supply

12V DC

Recommended distance from the camera

Between 6.5 to 14.7ft (2m to 4m) 10ftrecommended. Install blackbody at 6.5 to 13.12ft (2m to 4m) apart from the camera on a tripod, the wall, or the ceiling. The closer people walk by the blackbody, the more accurate the temperature reading will be).

Operating temperature and humidity

14°F ~ 104°F (-10°C ~ 40°C), under 80% humidity

Warranty

2 year warranty

SOFTWARE - MINIMUM HARDWARE REQUIREMENTS

CPU

Intel Core i5^® or higher (7th generation Intel Core or higher)

RAM

8GB or higher

HDD

Recommended for physical separation of HDD for program installation and HDD for data storage.

Video output

NVIDIA GTX 750 or higher (maintain the latest driver).
